The flat-type air hand with linear guides to increase accuracy and rigidity adopts a double piston method to achieve larger gripping force. Select from synchronous/ non-synchronous/ and long types according to workpiece requirements. The thin figure achieves height of 15mm in case of 6mm between the body surface and guides and 37mm in case of 18mm between the body surface and guides; while an option can be selected with stroke adjusting mechanism (in both opening and closing directions) for all models.
Bore size 6mm/8mm/12mm/14mm/18mm
Stroke12-80mm
Effective gripping force From12N{1.2kgf} at 6mm to 105N {10.7kgf} at 18mm
Specification
