The Koganei DA Series Slim Cylinders are stainless-steel tubing linear round body cylinders designed to meet various application needs. These cylinders offer innovative high-quality solutions with unmatched reliability. Let’s explore the details:
- DA Series Overview:
- Operation: Double Acting
- Bore Sizes (mm): 20, 25, 32
- Standard Strokes (mm): Vary based on bore size (e.g., 25 – 150 mm for 20mm bore)
- Max Stroke (mm): Up to 1050 mm
- Port Size: Rc 1/8 (upon request)
- Max Force (Push): Up to 283 N (64 lbf)
- Max Force (Pull): Up to 212 N (48 lbf)
- Speed Range: 30 – 800 mm/s (1.2 – 31.5 in/s)
- Pressure Range: 0.04 – 0.9 MPa (5.8 – 130.5 psi)
- Temperature Range: 0 – 70°C (32 – 158°F)
- Variations:
- DA: Double Acting
- DAC: Double Acting Adjustable Cushions
- DAB: Double Acting Block
- SUS-DA: Double Acting All Stainless Steel
- Applications:
- These cylinders are ideal for OEMs looking to improve performance and reduce machine size.
- Available in various styles and sizes, they cater to most applications.
Specification
