The PBDAS series includes the smallest diameter linear round body cylinders in the world (with bore sizes as small as 2.5mm), which allow machine and tool designers to miniaturize devices, machines, and automated processes. The Selection Guide provides a summary of the 45 different Pen Cylinder model variations available. PBDA Series Pen Cylinders offer:
- Bore Sizes from 2.5mm to 16mm
- High Temperature Operation
- Integrated Speed Control Option
- Stroke Adjustment Option
- Stainless Steel Tubes
- RoHS Compliance
Operations
| Double Acting | Double Acting Non-Rotating |
| Double Acting Adjustable Cushions | Double Acting Pull Side Stroke Adjusting |
| Double Acting Double Rod | Double Acting Tandem |
| Double Acting Dual Stroke | Single Acting Pull |
| Double Acting Heat Resistant | Single Acting Pull Non-Rotating |
| Double Acting Integrated Speed Controls | Single Acting Push |
| Double Acting Linear Bearing | Single Acting Push Clean System |
| Double Acting Low Pressure Hydraulic | Single Acting Push Non-Rotating |
| Double Acting Clean Dust Collecting Port |
Specification
Model List
- Double acting type
- ● Φ6 to 16 mm [0.236 to 0.630 in] cylinder bore. Complies with all model non-ion standards. Compact, light weight, and more durable. Used in manufacturing lines in a wide range of industries.
- Single acting push out type
- ● Φ6 to 16 mm [0.236 to 0.630 in] cylinder bore. Complies with all model non-ion standards. Single acting type with integrated return spring.
- Single acting pull
- ● Φ6 to 16 mm [0.236 to 0.630 in] cylinder bore. Complies with all model non-ion standards. Single acting type with integrated return spring.
- Non-rotating double acting type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Hexagon type non-rotating piston rod.
- Single acting non-rotating push out type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Single acting type with hexagon type non-rotating piston rod, and integrated return spring.
- Single acting non-rotating pull type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Single acting type with hexagon type non-rotating piston rod, and integrated return spring.
- Double acting double rod type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Cylinder with piston rods on both ends of the piston.
- Double acting push stroke adjustment type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Cylinder with stroke limiting stopper.
- Double acting pull stroke adjustment type
- ● Φ10 to 16 mm [0.394 to 0.630 in] cylinder bore size. Compatible with all model non-ion standards. Cylinder with stroke limiting stopper.
- Double acting type heat resistant type
- ● Φ6 to 16 mm [0.236 to 0.630 in] cylinder bore. Fluorine packing enables operating temperatures up to 150 degrees. However, a sensor switch cannot be equipped.
- Low hydraulic pressure: Double acting type
- ● Φ6 to 16 mm [0.236 to 0.630 in] cylinder bore. Pneumatic-hydraulic converter can be used for simple low-speed operation control of a cylinder operated by low hydraulic pressure.
